Maximum 5M Pixels USB3.0 Interface Digital Camera With The Maximum 210 FPS

Maximum 5M Pixels USB3.0 Interface Digital Camera With The Maximum 210 FPS
Maximum 5M Pixels USB3.0 Interface Digital Camera With The Maximum 210 FPS Maximum 5M Pixels USB3.0 Interface Digital Camera With The Maximum 210 FPS Maximum 5M Pixels USB3.0 Interface Digital Camera With The Maximum 210 FPS

Large Image :  Maximum 5M Pixels USB3.0 Interface Digital Camera With The Maximum 210 FPS

Product Details:
Place of Origin: China
Brand Name: Phidix
Certification: IATF16949,CE
Model Number: M21139
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: 1 PC/Carton
Delivery Time: 15-20 Work Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 1000 PCS/Month

Maximum 5M Pixels USB3.0 Interface Digital Camera With The Maximum 210 FPS

Description
Customization: OEM, ODM Packing: 1 PC/Carton
Warranty: 1 Year Lead-time: 15-20 Work Days
Supply Ability: 1000 PCS/Month Theory: Industrial Camera
Target: 1/2 Output Mode: HDMI、USB2.0x2
Frame Rate: 210FPS Resolution: 2592 X 2048
High Light:

USB3.0 Interface Digital Camera

,

Maximum 5M Pixels Digital Camera

,

210 FPS Microscope Digital Camera



Maximum 5M Piexls USB3.0 interface Digital Camera with the Maximum 210FPS



M21139 Maximum 5M Piexls USB3.0 interface Digital Camera with the Maximum 210FPS. This series digital camera adopts 8-storey high-density blind buried hole design, which is close to the aluminum shell to dissipate heat, effectively reducing the temperature. Low internal temperature ensures stable and reliable operation of the circuit, and the temperature outside the shell does not exceed 60 degrees.



Features:

  • The camera uses USB3.0 interface to transmit images.
  • Built-in 1GbDDR3 chip ensures stable transmission. Photo With 4-way opto-coupler isolation /O design, it can customize I/O usage and isolate interference at the same time, so as to meet the needs of external complex control.
  • The camera size is only: 29mmx29mmx30mm. Ultra-small size is suitable for the integrated installation of most industrial equipment.



Item Description / Value M21139A M21139B M21139C
Interface: USB3.0
Pixel: 1.3M
5M
Maximum Resolution: 1280x1024
2592x2048
Pixel size: 4.8μmx4.8μm
Target: 1/2
1
Data: 10bit
Exposure: By frame
FPS Output: 210FPS
71FPS
Color Output: Black
Colorful

Remarks: ● means standard configuration ○ means not available



Maximum 5M Pixels USB3.0 Interface Digital Camera With The Maximum 210 FPS 0

Maximum 5M Pixels USB3.0 Interface Digital Camera With The Maximum 210 FPS 1





Maximum 5M Pixels USB3.0 Interface Digital Camera With The Maximum 210 FPS 2
