WF10X 40X 100X 1000X Computer Lab Biological Microscope Digital Camera

WF10X 40X 100X 1000X Computer Lab Biological Microscope Digital Camera
WF10X 40X 100X 1000X Computer Lab Biological Microscope Digital Camera WF10X 40X 100X 1000X Computer Lab Biological Microscope Digital Camera

Large Image :  WF10X 40X 100X 1000X Computer Lab Biological Microscope Digital Camera

Product Details:
Place of Origin: China
Brand Name: Phidix
Certification: IATF16949,CE
Model Number: M12110
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: 1 PC/Carton
Delivery Time: 15-20 Work Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 1000 PCS/Month

WF10X 40X 100X 1000X Computer Lab Biological Microscope Digital Camera

Description
Color: White Customization: OEM, ODM
Packing: 1 PC/Carton Warranty: 1 Year
Drawtube: Trinocular Theory: Biological Microscope
Lead-time: 15-20 Work Days Supply Ability: 1000 PCS/Month
Eyepiece: WF10X Magnification: 40X-1000X
Nosepiece: Backward Quadruple Nosepiece Objective: Plan Achromatic 4X/10X/40X/100X
Condenser: Abbe N.A. 1.25(Iris Diaphragm) Focusing: Fine And Coarse Adjustment Focusing
Illumination: 3W LED Camera: Optional
High Light:

1000X Lab Biological Microscope

,

WF10X Computer Lab Biological Microscope

,

40X 100X digital camera microscope



High Quality 1000X Trinocular Biological Microscope With Digital Camera Connect To Computer



M12110 High Quality 1000X Trinocular Biological Microscope With Digital Camera Connect To Computer It’s with a stable and reliable system structure, easier and more comfortable operation are suitable for various working environments.



Features:



  • Teaching trinocular microscope with an inbuilt camera.
  • Ideal for teaching purposes, Designed for observing and projecting specimens in 3D.
  • Compatible to data projectors, Suitable for histology, microbiology, botany, virology and routine research applications.
  • Quality optics for showing the detail and color of any specimen.
  • Connectible to computer, television and projector (USB and HDMI)



Item Description / Value M12110
Theory: Biological microscope
Body: Ergonomics designed rigid frame. With handle for carry. All metal material with cover. Anti-fungi, anti-bacteria.
Optical system: Plan achromatic optical system
Observation method: Bright field
View tube:

Binocular/Trinocular head, 30 ° incling, 360°rotating.

Diopter adjustment on the left eyepiece.

Adjustment of inter-pupillary distance 50-75mm.

Eyepiece: Wide field WF10X / 18
  Optional 16X
Objective: Plan Achromatic Plan 4X/0.10, 10X/0.25, 40X/0.65(Spring loaded), 100X/1.25(Spring loaded and oil immersion)
Nosepiece: Quadruple reversed angle nosepiece, revolver with rotation on ball bearings
Illumination: White LED lamp illuminator. LED power: 3W, Color temperature: 6300K
Focusing mechanism:

Coaxial positioning system. Movement by roller guider (Roller and pinion). Rubber grip around fine and coarse adjust knob.

Tension adjustment of coarse regulation knob.

Upper limit stopper for protecting the lens and sample.

Stage:

Mechanical double layer stage, platinum with overhang, dimensions 155x145 mm.

Moving range: 76mm ×52mm.

Vernier scale on both axes of movement with an accuracy of 0.1mm.

Condenser: Removable Abbe condenser, NA1.25 with aperture iris diaphragm.
Camera:

5MP digital camera for microscope with USB and HDMI ports.

Connectible to computer, television and projector.

Software for win7/win10.

Accessories: Manual, dust cover, power cord of local standard.
Power supply: AC100-240V, 50/60Hz.

Note: ● means standard, ○ means optional



Packaging: 48.5*30.5*55.5CM

Weight: 7kg





WF10X 40X 100X 1000X Computer Lab Biological Microscope Digital Camera 0
