40X-1000X Student Biological Microscope Monocular Drawtube Portable Binocular

40X-1000X Student Biological Microscope Monocular Drawtube Portable Binocular
40X-1000X Student Biological Microscope Monocular Drawtube Portable Binocular 40X-1000X Student Biological Microscope Monocular Drawtube Portable Binocular 40X-1000X Student Biological Microscope Monocular Drawtube Portable Binocular 40X-1000X Student Biological Microscope Monocular Drawtube Portable Binocular 40X-1000X Student Biological Microscope Monocular Drawtube Portable Binocular

Large Image :  40X-1000X Student Biological Microscope Monocular Drawtube Portable Binocular

Product Details:
Place of Origin: China
Brand Name: Phidix
Certification: IATF16949,CE
Model Number: M11115
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: 1 PC/Carton
Delivery Time: 15-20 Work Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 1000 PCS/Month

40X-1000X Student Biological Microscope Monocular Drawtube Portable Binocular

Description
Color: White Customization: OEM, ODM
Warranty: 1 Year Drawtube: Monocular
Theory: Biological Microscope Lead-time: 15-20 Work Days
Supply Ability: 1000 PCS/Month Magnification: 40X-1000X
Eyepiece: WF10X/18mm Nosepiece: 4-Position
Viewing Head: 360 Rotatable Stage: Mechanical Stage With Size 140x130mm, X-Y Travel Is 78x30mm
Focusing: Coaxial Focusing Knob, Fine Focusing Is Graduated In Increment Of 2um Illumination: 3W LED Lamp
High Light:

40X-1000X Student Biological Microscope

,

Monocular Student Biological Microscope

,

Drawtube portable binocular microscope



40X-1000X Monocular Binocular Trinocular Series Drawtube Portable Student Biological Microscope



M11115 40X-1000X Monocular Binocular Trinocular Series Drawtube Portable Student Biological Microscope. The M11115 series biological microscope is designed to provide educators with a high performance; student proof instrument at an affordable price. The M11115 Series is an excellent choice for high schools, middle schools, technical institutes, hobbyists and home school applications. A classical designed LED illumination system provides bright, even illumination in both corded or cordless operation. Feature a variable, rechargeable LED illumination system allowing for you to use the microscope where ever you want – no cord required! Each microscope will work for approximately 3 to 4 hours on a single charge. More portable than ever, it’s easy for students and teachers to move the microscope around the classroom.



Features:



- LED illumination system is rechargeable and fitting for portable use.

- Same body with different view heads allow a comfortable upgrade of the microscope.

- It’s an economical version designed for education use.



Item Specification M11115A M11115B M11115C
Observation Tube: Monocular head inclined at 30°
  Binocular head inclined at 30°
  Trinocular head inclined at 30°
Interpupillary distance: From 52-75mm
Eyepiece: WF10X/18mm ●● ●●
Objectives: Achromatic 4X, 10X, 40X(spring), 100X(spring, oil)
Stage: Mechanical stage with size 140x130mm, X-Y travel is 78x30mm
Nosepiece: Quadruple Nosepiece
Focusing: Coaxial focusing knob, fine focusing is graduated in increment of 2um
Condenser: N.A. 1.25Abbe condenser with iris diaphragm
Illumination: 3W LED lamp
Power supply: 100-240V
Standard accessories: Dust cover, immersion oil, fuse, power cord
Optional accessories WF10X/20mm eyepiece ○○ ○○
WF10X/18mm pointer eyepiece ○○ ○○
WF10X/20mm reticule eyepiece ○○ ○○
20X achromatic objective
60X achromatic objective
C-mount adapter
digital camera adapter
digital camera eyepiece

Remarks: ● means standard ○ means optional



40X-1000X Student Biological Microscope Monocular Drawtube Portable Binocular 0  40X-1000X Student Biological Microscope Monocular Drawtube Portable Binocular 1  40X-1000X Student Biological Microscope Monocular Drawtube Portable Binocular 2

               M11115A                                                M11115B                                                  M11115C
