101.2 FPS Cmos USB Microscope Camera 640x480 Hardware Resolutions Range 3M Pixel

101.2 FPS Cmos USB Microscope Camera 640x480 Hardware Resolutions Range 3M Pixel
101.2 FPS Cmos USB Microscope Camera 640x480 Hardware Resolutions Range 3M Pixel 101.2 FPS Cmos USB Microscope Camera 640x480 Hardware Resolutions Range 3M Pixel 101.2 FPS Cmos USB Microscope Camera 640x480 Hardware Resolutions Range 3M Pixel 101.2 FPS Cmos USB Microscope Camera 640x480 Hardware Resolutions Range 3M Pixel

Large Image :  101.2 FPS Cmos USB Microscope Camera 640x480 Hardware Resolutions Range 3M Pixel

Product Details:
Place of Origin: China
Brand Name: Phidix
Certification: IATF16949,CE
Model Number: M21143
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Carton
Delivery Time: 15-20 Work Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 1000 PCS/Month

101.2 FPS Cmos USB Microscope Camera 640x480 Hardware Resolutions Range 3M Pixel

Description
Color: White Customization: OEM, ODM
Warranty: 1 Year Lead-time: 15-20 Work Days
Exposure: 0.1ms~2000ms Resolution: 2560x1922
Application: For Microscopes Pixel: 5M
Target: 1/2.5“ Frame Rate: 101.2FPS/640x480
Data Interface: USB3.0 Color Output: Colorful
High Light:

101.2 FPS usb microscope camera

,

3M Pixel 3.0 usb microscope camera

,

640x480 microscope cmos camera



Ultra-high Performance USB3.0 CMOS Camera With Hardware Resolutions Range From 3M to 18M



M21143 Ultra-high Performance USB3.0 CMOS Camera With Hardware Resolutions Range From 3M to 18M. M21143 is an ultra-high performance USB3.0 CMOS camera and it adopts ultra-high performance CMOS sensor as the image-picking device and USB3.0 is used as the data transfer interface. M21143 hardware resolutions range from 3.0M to 18M and come with the CNC aluminum alloy compact housing. M21143 comes with advanced video & image processing application Providing Windows/Linux/OSX multiple platforms SDK, Native C/C++, C#/VB.NET, DirectShow, Twain Control API. The M21143 can be widely used in bright field light environment and microscope image capture and analysis with higher frame rate.



Features:
- Standard C-Mount camera with Aptina CMOS sensor.
- With hardware resolution among 3.0M to 18M.
- CNC aluminum alloy housing.
- USB3.0 5 Gbps interface ensuring high frame rate.
- With advanced video & image processing application.
- Providing Windows/Linux/Mac OS multiple platforms SD.
- Native C/C++, C#/VB.NET, DirectShow, Twain Control API.



ItemSpecification
Sensor & Size:5.1M/MT9P006(C), 1/2.5“ (5.70x4.28)
Pixel:2.2x2.2μm
GResponsivity, Dynamicrange, SNRmax:1.76v/lux-sec, 67.74dB, 38.5dB
FPS/Resolution:14.2FPS/2560x1922, 38.3FPS/1280x960, 101.2FPS/640x480
Binning:1x1, 2x2, 4x4
Exposure:0.1ms~2000ms
Spectral Range:380-650nm (with IR-cut Filter)
White Balance:ROI White Balance/ Manual Temp Tint Adjustment/NA for Monochromatic Sensor
Color Technique:Ultra-Fine Color Engine/NA for Monochromatic Sensor
Capture/Control SDK:TWindows/Linux/macOS/Android Multiple Platform SDK(Native C/C++, C#/VB.NET, Python, Java, DirectShow, wain, etc.)
Recording System:Still Picture and Movie
Cooling System:Natural
Operating Temperature(in Centigrade):-10~ 50℃
Storage Temperature(in Centigrade):-20~ 60℃
Operating Humidity:30~80%RH
Storage Humidity:10~60%RH
Power Supply:DC 5V over PC USB Port
Operating System:

Microsoft® Windows® XP / Vista / 7 / 8 /10 (32 & 64 bit)

OSx(Mac OS X)

Linux

PC Requirements:

CPU: Equal to Intel Core2 2.8GHz or Higher

Memory:2GB or More

USB Port:USB3.0 High-speed Port

Display:17” or Larger

CD-ROM



  • Remarks: this series USB3.0 CMOS Camera has a hardware resolutions range from 3M to 18M.
ItemSensor & SizePixel(μm)

G Responsivity

Dynamic range

SNRmax

FPS/ResolutionBinningExposure
M21143A18M/AR1820(C)
1/2.3"(6.14x4.61)
1.25x1.25

0.62 V/lux-sec
65.8dB
36.3

5.6@4912x3684
18.1@2456x1842
32.2@1228x922
1x1,2x2,4x40.1ms~2000ms
M21143B16M/MN34120(C)
1/2.33“(6.18x4.66)
1.335x1.335

R: 2453LSB
Gr: 2444LSB
Gb: 1054LSB
B: 996LSB

6.0@4632x3488
15.0@2320x1740
26.0@1536x1160
1x1, 2x2,3x30.2ms~2000ms
M21143C16M/MN34230PLJ(C)
4/3“ (17.60x13.30)
3.8x3.8

R: 1315LSB
Gr: 2413LSB
Gb: 2413LSB
B: 1042LSB
(Gain = 0dB)

6.0@4648x3506
15.0@2304x1750
30.0@1536x1168
1x1,2x2,3x30.06ms~15s
M21143D16M/MN34230ALJ(M)
4/3“ (17.60x13.30)
3.8x3.8

A: 2650LSB
B: 2650LSB
C: 2650LSB
D: 2650LSB
(Gain = 0dB)

22@4640x3506
36@3840x2160
43@2304x1750
43@1920x1080
49@1536x1168

1x1,
1x1,
2x2,
2x2,
3x3
0.224ms~15s
M21143E14M/MT9F002(C)
1/2.3“(5.73x4.60)
1.4x1.4

0.724v/lux-sec
65.3dB
35.5dB

6.2@4096x3286
20.8@2048x1644
53.3@1024x822
1x1,
2x2,
0.224ms~2000ms
M21143F10M/MT9J003(C)
1/2.3“ (5.98x4.58)
1.67x1.67

0.31v/lux-sec
65.2dB
34dB

7.2@3584x2746
24.5@1792x1372
1x1,2x2,4x40.4ms~2000ms
M21143G10M/MT9J003(M)
1/2.3“(5.98x4.58)
1.67x1.67

0.4v/lux-sec
65.2dB
34dB

7.2@3584x2746
24.5@1792x1372
1x1,2x2,4x40.4ms~2000ms
M21143H8.5M/Special(C)
1/2.4“(5.56x4.26)
1.67x1.67

0.31v/lux-sec
65.2dB
34dB

8.3@3328x2548
26.2@1664x1272
1x1,2x2,4x40.1ms~2000ms
M21143J5.1M/MT9P006(C)
1/2.5“ (5.70x4.28)
2.2x2.2

1.76v/lux-sec
67.74dB
38.5dB

14.2@2560x1922
38.3@1280x960
101.2@640x480
1x1,2x2,4x40.1ms~2000ms
M21143K3.1M/AR0330(C)
1/3“ (4.51x3.38)
2.2x2.2

1.9v/lux-sec
100dB
39dB

27.3@2048x1534
53.3@1024x770
1x1, 2x20.1ms~2000ms
